Single Jet Brass Body Cold Water Meter
  • Single Jet Brass Body Cold Water MeterSingle Jet Brass Body Cold Water Meter
  • Single Jet Brass Body Cold Water MeterSingle Jet Brass Body Cold Water Meter
  • Single Jet Brass Body Cold Water MeterSingle Jet Brass Body Cold Water Meter

Single Jet Brass Body Cold Water Meter

The following is an introduction to single jet brass body cold water meter, I hope to help you better understand single jet brass body cold water meter. Welcome new and old customers to continue to cooperate with us to create a better future together!

Send Inquiry

Product Description

1. Features of Single Jet Brass Body Cold Water Meter

Dry-dial, magnetic drive, protected against external magnetic tampering;

Dry register and register with 5 or 8 numbered roller;

Vacuum-sealed register, frost resistant, keeps clear reading for long time;

Brass body or plastic body, optional;

Brass body can be painted or nickel coated;

High accuracy;

Measuring unit is m ;

The meters conform to ISO4064 Standard Class B.

2. Working condition of Single Jet Brass Body Cold Water Meter

Water temperature≤30℃; hot water meter≤ 90℃.

Water pressure≤1MPa(PN:1.6MPa/16bar)

ΔP≤0.1MPa

3. Accuracy of Single Jet Brass Body Cold Water Meter

From minimum flow-rate(qmin) inclusive, to transitional flow -rate(qt) exclusive:±5%

From transitional flow -rate(qt) inclusive, to overload flow -rate(qs) exclusive:±2%(Hot water meter: ±3%)

4. Upon request of Single Jet Brass Body Cold Water Meter

Remote transmission device can be added upon request

Pulse output :IL,10L

5. Head Loss Curve of Single Jet Brass Body Cold Water Meter

6. Error Curve of Single Jet Brass Body Cold Water Meter

7. Dimension of Single Jet Brass Body Cold Water Meter

Type Size
(mm)
Length
(mm)
L
Width
(mm)
w
Height
(mm)
H
Connecting
Thread
D
Weight
(kg)
LXSG(R)-13D3 15 110 77 80 G3/4"B 0.57
LXSG(R)-20D3 20 130 77 80 G1"B 0.67
LXSG(R)-25D3 25 160 77 85 G11/4"B 0.91
LXSG(R)-32D3 32 160 101.5 120 G11/2"B 1.41
LXSG(R)-40D3 40 200 101.5 120 G2"B 1.65

8. Main technical data of Single Jet Brass Body Cold Water Meter

Nominal
Size
DN(mm)
Class of
measurement
Overload
Flow-rate
qs(m3/h)
Permanent
Flow-rate
qp(m3/h)
Transitional
Flow-rate
qt(l/h)
Minimum
Flow-rate
qmin(l/h)
15 B 3 1.5 120 30
20 B 5 2.5 200 50
25 B 7 3.5 280 70
32 B 12 6.0 480 120
40 B 20 10 800 200

FAQ

Q. Are you the factory?

A. Yes. We are factory. WENLING YOUNIO WATER METER was established in 1983, specializes in producing all kinds of water meters and spare parts. Welcome to visit to our factory anytime.

Q. What kind of certification do you have ?

A. ISO4064, CE certificate, MID certificate, NSF certificate, ROHS certificate.

Q.How to request a quotation from YOUNNIO?

A. Simply call or send us E-mail with your purchase request. If detail requirements (like the type, size, weight ,package and so on) can be shared will be better for quick quotation.

Q.What are your quality control procedures?

A.YOUNIO strictly get the control of quality, which begin with material purchase and carry through to the end of the production process by ISO9001 management system.Before shipping, welcome the examination of goods.

Q. Do you offer OEM service.

A. Yes. We have a professional D&D team to follow requires proof of trademark registration in order to print or emboss your trademark onto the product or packaging.

Q. Do YOUNIO products come with a warranty ?

A. Yes. We backs our products100% generous 2 year warranty.
